CG481-S6053

The CG480-S6053 Series GPU Server is engineered for high-performance computing and AI workloads, featuring a switching GPU topology that supports up to eight dual-slot GPU accelerators within a 4U rackmount chassis. Powered by dual AMD EPYC 9005 Series processors, the system is based on the NVIDIA MGX modular architecture, enabling flexible integration of GPUs, CPUs, and DPUs. This modular design allows for optimized system configurations tailored to diverse enterprise data center applications, including AI training, inference, and data analytics.

XpertStation WS300

Powered by the NVIDIA GB300 Grace Blackwell Ultra Desktop Superchip and 748GB of large coherent memory, MSI¡¦s XpertStation WS300 on NVIDIA DGX Station™ architecture delivers data-center-class performance for AI training, inference, and simulation workloads, right from your deskside.

EdgeXpert MS C931¡iNVIDIA DGX™ Spark Platform¡j

¡iEdgeXpert MS C931¡j NVIDIA® Grace Blackwell Architecture: - NVIDIA Blackwell GPU & Arm 20-core CPU - NVIDIA® NVLink®-C2C CPU-GPU memory interconnect 128 GB LPDDR5x coherent, unified system memory 1000 AI FLOPS (FP4) AI performance Full stack solution, hardware & software, designed for AI developers

S2206 series

¡iS2206¡j Dual 4th/5th Generation Intel® Xeon® Scalable Processors, TDP up to 350W (32) DDR5 DIMM slots, 16 channels(2DPC), RDIMM/3DS Up to (7) PCIe Add-on cards (12) Hot-swap 3.5"/2.5" drive bays/(24) hot-swap 2.5" drive bays (1+1) 2000W/1600W Redundant CRPS PSU 80+ Platinum Dual BIOS & BMC

S2205 series

¡iS2205 series¡j Dual 4th/5th Generation Intel® Xeon® Scalable Processors, TDP up to 350W (32) DDR5 DIMM slots, 16 channels(2DPC), RDIMM/3DS Up to (7) PCIe Add-on cards (12) Hot-swap 3.5"/2.5" drive bays/(24) hot-swap 2.5" drive bays (1+1) 2000W/1600W Redundant CRPS PSU 80+ Platinum Dual BIOS & BMC

CG290-S3063

¡iCG290-S3063¡j 2U (NVIDIA MGX™ architecture) Single Intel® Xeon® 6500P-series and 6700P-series processor with 136 PCIe lanes, TDP up to 350W (16) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC) (4) Rear hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports Max (7) PCIe 5.0 x16 expansion slots, supporting up to (4) NVIDIA H200 NVL or RTX PRO 6000 Blackwell Server Edition PCIe GPU cards (1) 1000Base-T Dedicated Server Management port with: ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support Dual BIOS & BMC TPM2.0 on board Hardware Root of Trust is supported as optional

CG480-S5063

¡iCG480-S5063¡j 4U (NVIDIA MGX™ architecture) Dual Intel® Xeon® 6500/6700 series processors, TDP up to 350W (32) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC) (20) Front hot-swap E1.S PCIe 5.0 x4 NVMe drive bays (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports Max (13) PCIe 5.0 x16 expansion slots, supporting up to (8) NVIDIA H200 NVL or or RTX PRO 6000 Blackwell Server Edition PCIe GPU cards (2) 10GBase-T Ethernet Ports with Intel® X710-AT2 (NCSI supported) (1) 1000Base-T Dedicated Server Management Port with: ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support Dual BIOS & BMC TPM2.0 on board Hardware Root of Trust is supported as optional

G4201 series

¡iG4201¡j 4U Dual 4th/5th Generation Intel® Xeon® Scalable Processors (32) DDR5 DIMM Slots, 2DPC, up to 5600MT/s, RDIMM (8) PCIe 4.0 or 5.0 x16 slots, supporting (8) NVIDIA RTX 6000 Ada Generation Graphics cards or L40S PCIe GPU cards (2) PCIe 4.0 x16 slots (one with x8 signal) or (1) PCIe 4.0 x16 slots (12) Hot-swap 3.5"/2.5" drive bays support NVMe or SATA devices (1)1000Base-T Ethernet port (Intel® I210AT) BMC ASPEED AST2600 with IPMI & DMTF Redfish Support

G4101 series

¡iG4101 series¡j 4U Single Socket SP5, supports AMD EPYC™ 9005/9004 series processors (12) DDR5 DIMM Slots, 1DPC, up to 6400MT/s, RDIMM/RIMM-3DS (4) PCIe 5.0 x16 slots (2) PCIe 4.0 x16 slots (x8 signal) (12) Hot-swap 2.5¡¨ U.2 PCIe 4.0 NVMe drive bays (1) 1000Base-T Dedicated Server Management Port (1) ASPEED AST2600 with IPMI & DMTF Redfish Support, Dual BMC Flash Closed Loop Liquid Cooling module or Air Cooling module for CPU
